Products lineup
Please refer to the catalog for detailed dimensional information.
| Model | Boundary dimensions [mm] | |||||||
| D | B | C | L | Da | Screw specification |
Rosette coined | Part No. | |
| 1 | 19 | 6 | 0.5 | 8 | 8.2 | M6 P1.0 | – | A-19-B0.5-M6×8 |
|---|---|---|---|---|---|---|---|---|
| 2 | 1 | ● | A-19-B1 | |||||
| 2 | 2 | ● | A-19-B2 | |||||
| 2 | 3 | ● | A-19-B3-M6×8 | |||||
| 1 | 22 | 7 | 0.5 | 8 | 9.5 | M6 P1.0 | – | A-22-B0.5 |
| 2 | 1 | ● | A-22-B1-M6×8 | |||||
| 2 | 2 | ● | A-22-B2 | |||||
| 3 | 8 | 2 | 11 | 11 | – | A-22-B2-11 | ||
| 2 | 7 | 3 | 11 | 9.5 | ● | A-22-B3-M6×8 | ||
| 2 | 4 | 11 | ● | A-22-B4-M6×8 | ||||
| 2 | 5 | 11 | 11 | ● | A-22-B5-M6×8 | |||
| 2 | 6 | ● | A-22-B6 | |||||
| 3 | 24 | 8 | 2 | 11 | 11 | M6 P1.0 | – | A-24-B2-11 |
| 3 | 26 | 8 | 2 | 11 | 11 | M6 P1.0 | – | A-26-B2-11 |
Components of product name
If you would like to know more about the meaning of the product name codes, please see the configuration of part numbers.
| No | Item | Symbol | Meaning |
| ① | Outer race material symbol | A | Carbon steel (Plating) |
| ② | Outer race shape symbol | （R） | Flat *Omitted |
| ③ | Retainer or full ball type | Omitted | Retainer (Polypropylene) |
| S | Full ball | ||
| ④ | Outer race outer diameter | – | (Numerical ΦD dimension shown in drawing) |
| ⑤ | Ball material symbol | Omitted | Carbon steel ball |
| ⑥ | Inner race shape symbol | B | Screw shaft |
| ⑦ | Inner race material symbol | Omitted | Carbon steel (Plating) |
| ⑧ | Bore and clearance dimension for mounting | – | (Numerical C dimension shown in drawing) |
| ⑨ | Additional information | M6×8 | Screw specification × Screw length L dimension |
| 11 | Numerical L dimension shown in drawing *Including omitted |
*All products are basically made to order, but some items may be in stock. Please contact your distributor or dealer for availability.
