| No |
Item |
Symbol |
Meaning |
| ① |
Outer race material symbol |
IN |
Polyamide (Carbon steel insert bearing) |
| ② |
Outer race shape symbol |
(R) |
Flat *Omitted |
| ③ |
Retainer or full ball type |
Omitted |
Retainer (Polypropylene) |
| ④ |
Outer race outer diameter |
– |
(Numerical ΦD dimension shown in drawing) |
| ⑤ |
Ball material symbol |
Omitted |
Carbon steel ball |
| ⑥ |
Inner race shape symbol |
B |
Screw shaft |
| ⑦ |
Inner race material symbol |
Omitted |
Carbon steel (Plating) |
| ⑧ |
Bore and clearance dimension for mounting |
– |
(Numerical C dimension shown in drawing) |
| ⑨ |
Additional information |
M6×8 |
Screw specification × Screw length L dimension |
